UHTES
Standoff Through The Wall Radar
The Standoff Through The Wall Radar (UHTES) is a radar system used to obtain location information of the target elements, which are located in enclosed areas where there is no visual access, from a secure distance and without approaching the target area, through ultra-wideband (UWB) radar signals.
UHTES has been designed to be integrated onto Tactical Wheeled Armored Vehicles, Armored Personnel Carriers and Mine-Protected Armored Vehicle systems. Thanks to its long-range penetration capability, the system can transmit to the friendly elements the location information of living beings from a safe distance in cases where it is risky to approach the targeted structure.
Apart from various military operations, such as hostage rescue, counter-terrorism and internal security operations, UHTES can also be used for various civilian purposes, including firefighting and post-disaster rescue operations. The system can detect stationary and moving targets hidden in enclosed environments or behind obstacles.
Download BrochureMain Features
- Long range target detection
- Ability to integrate with TTZA, ZMA and MRAP type vehicles
- Vertical and horizontal two-axis movable antenna system
- High distance resolution
- Effective penetration capacity against different types of obstacles
- Sensitivity to macro and micro movements
- Working with built-in rechargeable battery or feeding from the vehicle's power unit
- Two-dimensional location estimation
- In-device test (idt) capability
- Jamming-resistant
- Metal coated wall warning capability
- Wall distance identification capability
- Battery operation time (full use mode)
- MIL- STD -810 compatibility
- MIL- STD -461 compatibility
- Save and replay the task
- Wall detection
- Built-in test (BIT) feature
- Foreign language support
Technical Features
| Size | : Antenna Unit: 150 cm x 40 cm x 40 cm |
| Detection Distance | : 35 m (in free field) |
| Motion Detection | : Macro and micro movements |
| Wall Types | : Brick, plasterboard, wood, plastic, concrete, etc. |
| Mechanically Controlled Antenna System Moving Vertical and Horizontal |
: Available |
| Angle of View | : 90° |
| Display Type | : 2 Dimensional |
| Screen Size | : 19" |
| Power Type | : Rechargable battery or feeding from the vehicle’s powerunit |
| Lifespan of Battery (Including Standby Time) | : 2.5 Hours (50% RF on, 50% standby mode) |
| Lifespan of Battery (100% Operational) | : 1,5 Hours |
